Goodrive390L Series Lift-Dedicated VFD
Function
code
Selection 1 of
P07.05 parameters displayed in
running state
Selection 2 of
P07.06 parameters displayed in
running state
Selection of parameters
P07.07
displayed in stopped
202403 (V1.0）
Name
Setting range: 0–3
0: Valid for keypad control only
1: Valid both for keypad and terminal
control
2: Valid both for keypad and
communication control
3: Valid for all control modes
Setting range: 0x0000–0xFFFF
BIT0: Running speed (m/s on)
Bit1: Set speed (m/s blinking)
Bit2: Bus voltage (V on)
BIT3: Output voltage (V on)
BIT4: Output current (A on)
BIT5: Running speed (rpm on)
Bit 6: Output power (% on)
Bit 7: Output torque (% on)
Bit 8: Reserved
Bit 9: Reserved
BIT10: Input terminal status
Bit11: Output terminal status
Bit 12: Reserved
Bit 13: Reserved
Bit14: Reserved
Bit 15: Reserved
Setting range: 0x0000–0xFFFF
Bit 0: AI1 (V on)
Bit 1: AI2 (V on)
Bit 2: Reserved
Bit 3: Reserved
Bit 4: Reserved
Bit5: Reserved
Bit6: Ramp reference speed (m/s on)
Bit 7: Linear speed
Bit 8: Reserved
Bit9: Upper limit frequency (Hz on)
Setting range: 0x0000–0xFFFF
Bit0: Set speed (m/s on, blinking
Description
Function parameter list
Default Modify
0x0FFF ○
0x0000 ○
0x00FF ○
173
