Enable The Use Of Overlay Data A - Micromeritics TRISTAR II PLUS Operator's Manual

A Advanced Reports - Python Module
E U
NABLE THE SE OF
1. On the Report Options tab, click Overlays.
2. On the Plot Overlay Sample Selection window, to move a file from the Available Files list
box to the Selected Files list box, either double-click a file name in the Available Files list
box or click one or more files in the Available Files list box then click Add.
3. Click OK.
4. On the Report Options tab, highlight Advanced in the Selected Reports list box.
5. Click Edit.
6. Select the Overlay samples checkbox to the right of the selected report.
7. Click OK.
8. Run the script using the instructions found in
A - 16
O D
VERLAY ATA
Scripts on page A - 4.
TriStar II Plus Operator Manual
303-42800-01 (Rev M ) — Sep 2023
