F-Ratio Method Report - Micromeritics TRISTAR II PLUS Operator's Manual

-R M
F ATIO ETHOD
The f-Ratio report uses the measured isotherm and normalizes it using a reference isotherm.
f-Ratio Report
Selections
Pressures [button]
Reference isotherm
[group box]
TriStar II Plus Operator Manual
303-42800-01 (Rev M ) — Sep 2023
R
EPORT
Description
Use to select a pressure range for report calculations and points for
exclusion from calculations.
Calculation pressure range. Enter the minimum and maximum
pressures to be used in the pressure table.To exclude a point from
the calculations used to generate the report, select Exclude.
Exclude All. Select to exclude all pressure points in the table.
Include All. Select to include all pressure points in the table.
Browse to select a sample file to use as a reference for the isotherm.
Select a file containing an isotherm measured from a non-porous
sample of the same material as the current sample.

f-Ratio Method Report

8 - 27
