4 Parameter Files
Analysis Conditions (continued)
Selections
p° and T [button]
4 - 10
Description
Values used to determine how close the actual pressure must be
to each target pressure from the pressure table. At lower
pressures, the relative tolerance value is lower. At higher
pressures, the absolute tolerance value is lower.
Experiment 1. There might be an absolute tolerance of 5 mmHg,
a relative tolerance of 5%, and a target pressure of 40 mmHg; 5%
of 40 mmHg is 2 mmHg. Since 2 mmHg (relative tolerance) is
lower than 5 mmHg (absolute tolerance), 2 mmHg is used.
Therefore a minimum pressure of 38 mmHg (40 - 2) must be
attained to collect data for a target pressure of 40 mmHg.
Experiment 2. There might be an absolute tolerance of 5 mmHg,
a relative tolerance of 5%, and a target pressure of 200 mmHg;
5% of 200 mmHg is 10 mmHg. Since 5 mmHg (absolute
tolerance) is lower than 10 mmHg (relative tolerance), 5 mmHg is
used. Therefore a minimum pressure of 195 mmHg (200 - 5) must
be attained to collect data for a target pressure of 200 mmHg.
Normally, surface area measurement points are widely spaced
and the resulting measurement is not very sensitive to the precise
location of points so wider tolerances may be used.
Unnecessarily tight tolerances lengthen the analysis.
Click to select one option for obtaining the saturation pressure (Po)
and analysis bath temperature. Each selected option presents a
different set of parameters at the bottom of the window.
Options and descriptions:
1. Analysis bath temperature (not used for krypton analyses).
Measures the p
0
urement of each data point without slowing the analysis.
on a continuous basis. Allows the meas-
