1 A C
NALYZER
Parts and accessories are located on the
F C
RONT OMPONENTS
Front Components
Component
P tube
0
Power indicator
light
Sample ports
Elevator
TriStar II Plus Operator Manual
303-42800-01 (Rev M ) — Sep 2023
OMPONENTS FOR
Micromeritics
A. P0 tube
B. Power indicator light
C. Sample ports
D. Elevator
Description
For measuring the saturation pressure.
Blinks when power is applied to the analyzer; illuminates when the ana-
lysis program is initiated and ready for operation.
For installing up to three sample tubes.
Allows placement of the Dewar around the sample and P
elevator is raised automatically when the analysis is started and lowers
automatically upon completion. During analysis, the elevator optionally
lowers after the free space measurement to allow evacuation, then is
raised and continues the analysis.
1 Analyzer Components for TriStar II Plus
T S II P
RI TAR LUS
web page.
tubes. The
0
1 - 1
