Option Presentation - Micromeritics TRISTAR II PLUS Operator's Manual

2 About the Software
O P
PTION RESENTATION
Options > Option Presentation
For 21CFR11 environments, see
- 26.
Use to change the way sample files and parameter files display: Advanced, Basic, or Restricted.
Each display option shows sample information and options differently.
Option Presentation Display
Presentation Display
Advanced
Basic
Restricted
Show Degas
Conditions
Show Splash Screen
To change the view for the selected window, use the drop-down list at the bottom of
the sample file editor.
2 - 10
Software in 21CFR11 Environments on page 2
Description
Displays all parts of sample and parameter files. Navigate to para-
meter windows by selecting the tabs across the top of the window.
Displays sample information in a single window. This display option
is used after the parameter files have been created. The previously
entered or default parameter files are then accessible using drop-
down lists.
Displays the sample file in a single window like the Basic display
option with certain functions disabled. A password is set when the
Restricted option is selected. That same password must be entered
to change to the Basic or Advanced display option. This display type
is typically used in laboratories — such as the pharmaceutical
industry — where analysis conditions must remain constant. The
Advanced option is not available in the view selector at the bottom of
the window when using the Restricted display option.
When enabled, displays the Degas Conditions tab when using
Advanced option presentation and the Degas Conditions drop-down
list when using Basic or Restricted option presentation. This option
may be deselected to hide the Degas Conditions tab if not using a
Smart VacPrep.
Enables (or disables) the splash screen upon application startup.
TriStar II Plus Operator Manual
303-42800-01 (Rev M ) — Sep 2023
