9 Diagnostics
Start Diagnostic Test
Selections
Comments [text box]
Estimated time (min.)
[text box]
File [group box]
Next [button]
Operator [text box]
Repeat [button]
Report after test
[check box]
Sequence
Start [button]
Test [drop-down box]
For fields and buttons not listed in this table, see
Buttons on page 2 -
9 - 2
Description
Displays comments from the selected diagnostic test.
Approximate time for test completion.
Shows a status bar of steps complete once the test begins.
Starts the next test.
Enter information to identify the person running the service test.
Repeats the selected diagnostic test.
Automatically generates reports to the selected destination when the
test is complete.
Sequence number assigned to the test.
Starts the diagnostic test.
Select the diagnostic test to be performed.
3.
Common Fields and
