Micromeritics TRISTAR II PLUS Operator's Manual page 19

R P C
EAR ANEL OMPONENTS
Rear Panel Components
Component
Maximum inlet
A
pressure
Vacuum pump
B
connector
Helium inlet
C
valve
Gas inlet valves Inlet valves for analysis gases.
D
Power cord
E
connector
and power
switch
TriStar II Plus Operator Manual
303-42800-01 (Rev M ) — Sep 2023
Rear panel
Description
Indicates the maximum inlet pressure that can be used.
For attaching the vacuum pump hose.
Inlet valve for helium.
For connecting the analyzer to the power supply and for powering the
analyzer on and off.
1 Analyzer Components for TriStar II Plus
Power switch
1 - 3
