I M
MPORT ANUALLY
When importing isotherm data from an external ASCII text file using the
interactive window, the ASCII text file must use the following rules:
ASCII text file format rules
Data must be in two columns and separated by a comma or white-space. Acceptable column
headings are:
Relative Pressure
n
Absolute Pressure (mmHg)
n
Absolute Pressure (kPa)
n
Absolute Pressure (mBar)
n
Sample Physisorption ASCII Text File
Silica Alumina : Adsorption
Relative Pressure Quantity Adsorbed (cm3/g STP)
0.108629 50.6657
0.22288 60.7813
0.339909 71.3095
0.459512 84.4172
0.577447 102.672
0.654583 121.707
0.760074 179.096
0.855713 334.565
0.958511 394.675
0.996251 403.793
Silica Alumina : Desorption
Relative Pressure Quantity Adsorbed (cm3/g STP)
0.996251 403.793
0.86016 389.626
TriStar II Plus Operator Manual
303-42800-01 (Rev M ) — Sep 2023
E D
NTERED ATA
n
n
n
Import
Quantity Adsorbed (mmol/g)
Quantity Adsorbed (cm³/g STP)
Quantity Adsorbed (cm
Manually Enter Data
button on the
3
/g STP)
3 - 9
