t-Plot Report (continued)
Selections
t-Plot [check box]
For fields and buttons not listed in this table, see
Buttons on page 2 -
TriStar II Plus Operator Manual
303-42800-01 (Rev M ) — Sep 2023
Description
To import values from an existing thickness curve (.THK file), click
Open, then select the file containing the values. The table to be
imported must have a .TXT or .THK file extension and have a two-
column format with the relative pressures in the first column and the
thickness values in the second column. Columns must be separated
by a space or a tab.
Use to have a graphical representation of data generated.
Autoscale x-axis. The x-axis field shows the statistical thickness of
the adsorbed film.
Autoscale y-axis. The y-axis field shows the quantity of gas
adsorbed.
Overlay samples. Use to overlay sample files on the t-plot.
3.
