8 Selected Report Options
Dubinin Pore Volume Report Options
In the Dubinin Report Options window, highlight dV/dw Pore Volume in the Selected Reports list
box, then click Edit.
This option plots differential pore volume as a function of pore width.
Dubinin Report
Selections
Autoscale x-axis /
Autoscale y-axis
[check box]
Overlay samples
[selection]
Plot curve / Plot points
[selection]
For fields and buttons not listed in this table, see
Buttons on page 2 -
8 - 24
Description
Select an option to have the x- and/or y-axes scaled automatically.
Both axes begin at 0; the system uses the highest values collected
during analysis as the ending points for axis ranges.
Enable to enter beginning and ending values manually.
Use to overlay sample files on the plot.
Select to plot points on the graph.
3.
Common Fields and
