8 Selected Report Options
BJH Plot
The fields for all plot options are identical for specifying plotting methods and customizing plots.
Highlight any plot option in the Selected Reports list box in the BJH Report Options window, then
click Edit.
BJH Plot Report
Selections
Autoscale [check box]
Plot curve / Plot points
[check box]
X-Axis [group box]
Y-Axis [group box]
For fields and buttons not listed in this table, see
Buttons on page 2 -
8 - 12
Description
When enabled on the report parameters windows, allows the x- and
y- axes to be scaled automatically. Autoscale means that the x- and
y- ranges will be set so that all the data is shown. If Autoscale is not
selected, the entered range is used.
Select to plot points on the graph.
Use to have the x-axis on a logarithmic or linear scale.
Overlay. Select an option to overlay onto the current report.
Variable. Select a variable.
3.
Common Fields and
TriStar II Plus Operator Manual
303-42800-01 (Rev M ) — Sep 2023
