Micromeritics TRISTAR II PLUS Operator's Manual page 148

7 About Reports
If overlaying this type of
report...
Isotherm
n
Alpha-S Method
n
BET Surface Area
n
f-Ratio Method
n
Freundlich
n
Langmuir Surface Area
n
t-plot
n
Temkin
n
BJH
n
Dollimore-Heal
n
MP-Method
n
5. On the Report Options tab, click Overlays.
6. On the Plot Overlay Sample Selection window, move up to 25 files from the Available Files
box to the Selected Files box:
7. Click OK.
8. To view the report, click Preview.
7 - 32
Then...
a. On the Isotherm Report Options window, select one or
more plots in the Selected Reports group box, then click
Options to the right of the selected plot.
b. On the Plot Options window, select Plot curve and/or Plot
points if they are to be included in the overlay. If the x-
and/or y-axes are to be autoscaled, enable Autoscale; oth-
erwise, enter the From and To points for the axes. Click
OK.
c. On the Isotherm Report Options window, in the Plot
Options group box, select Plot overlays. Click OK.
d. Continue to Step 5.
a. On the pop-up window, select Overlay samples. Verify
other fields. Click OK.
b. Continue to Step 5.
a. Select the report variable from the Selected Reports
group box, then click Edit.
b. Click the down arrow on the Overlay field, then select the
Samples option.
c. Verify other fields.
d. Click OK.
e. Click OK again.
TriStar II Plus Operator Manual
303-42800-01 (Rev M ) — Sep 2023
