Power - Micromeritics TRISTAR II PLUS Operator's Manual

P
OWER
The TriStar II Plus is designed to operate with universal input power supply (100-240 VAC, 50/60
Hz, 150 VA). Noise-free power of the correct voltage and frequency, with a safety earth ground,
should be available through a standard wall receptacle. The power outlet should be able to supply
15 amps @ 100 or 115 VAC ±10% or 7.5 amps @ 230 VAC ±10%. These requirements can be
checked by using a circuit analyzer (available at most hardware or electronic supply houses) or a
multimeter. There should also be sufficient outlets for the computer, dry roughing pump, monitor,
printer, and any other peripheral devices.
The power cord, IEC, 300V, 10A (available in the accessories kit) should be connected to noise-
free power of the correct voltage and frequency, with a safety earth ground, through a standard
wall receptacle.
The analyzer and peripheral devices must be installed on their own dedicated power
line. Other devices — such as motors, generators, or ovens — should not be placed
on the same power line.
Replacement power supply cords must be rated for the specifications stated above.
TriStar II Plus Operator Manual
303-42800-01 (Rev M ) — Sep 2023

Power

11 - 3
