Micromeritics TRISTAR II PLUS Operator's Manual page 60

3 Sample Files
Sample Files (continued)
Selections
Mass [group box]
Method [drop-down box] Select a method from the drop-down list.
Operator [text box] *
Sample [text box] *
Sample Tube
[drop-down box]
Submitter [text box] *
Type of Data
[group box]
User Parameters
[group box] *
For fields and buttons not listed in this table, see
Buttons on page 2 -
* This field label may have been renamed or may not display if modified in Options > Default
Methods.
3 - 4
Description
Enter a value for sample mass. Mass can be changed any time
before, during, or after analysis.
Enter. Enables the Sample mass field. Enter a value for the sample
mass.
Calculate. Enables the Empty tube and Sample + tube fields. Enter
the values necessary to calculate the sample mass. Equation used
to calculate sample mass:
Mass = Mass
sample
Enter operator identification information.
Enter a sample description.
Select a sample tube file from the drop-down list, or click
modify or create a new sample tube file.
Enter submitter identification information.
Automatically collected. Select if the type of data will be
automatically collected by the system while an analysis is running.
Manually entered. Use to enter data manually that was collected
from another source. If Manually entered is selected, the Isotherm
Report becomes available in the Basic/Advanced drop-down list for
pasting or importing data into the file.
See Manually Enter Data on page 3 -
These fields are primarily used for the SPC (Statistical Process Con-
trol) reporting to specify sample characteristics or its manufacturing
process but may be used for other data by entering specific analysis
conditions or sample criteria. The entered parameters display on the
SPC Report.
3.
– Mass
sample+tube tube
7.
Common Fields and
TriStar II Plus Operator Manual
303-42800-01 (Rev M ) — Sep 2023
Edit to
