8 Selected Report Options
t-Plot Report (continued)
Selections
Selected Reports
[group box]
Surface area correction
factor [text box]
Surface Area
[group box]
Thickness Curve
[group box]
8 - 52
Description
Tabular Report. Use to have a tabular report of data generated.
t-Plot. Use to have a graphical representation of data generated.
Autoscale x-axis. The x-axis field shows the statistical thickness
n
of the adsorbed film.
Autoscale y-axis. The y-axis field shows the quantity of gas
n
adsorbed.
Overlay samples. Use to overlay sample files on the t-plot.
n
Enter the value to correct for surface areas that are not smooth. This
brings the values for BET surface area and micropore surface area
into accordance. For most samples, the default value of 1.000 is
adequate.
Select the surface area value used for thickness calculations. BET is
the most commonly used option.
Select the thickness curve, then click
equation for the selected curve. The Frenkel-Halsey-Hill thickness
curve can be applied using the Halsey option.
Kruk-Jaroniec-Sayari / Halsey / Harkins and Jura / Broekhoff-
de Boer / Carbon Black STSA. Select the thickness curve option,
then click Edit. Modify the equation for the selected curve as
needed.
Reference. Select Reference, then click
entering both the relative pressure and thickness values. One
predefined curve is shipped with the analysis program and is found in
the Reference directory.
Edit to modify the values in the
Edit to define a t-curve by
