Heat of Adsorption Report (continued)
Selections
Heat of adsorption plot
[selection]
Isostere plot [selection]
Remove Sample
[button]
Show graphic
[check box]
Show report title
[check box]
Tabular report
[check box]
For fields and buttons not listed in this table, see
Buttons on page 2 -
TriStar II Plus Operator Manual
303-42800-01 (Rev M ) — Sep 2023
Description
Insert Range. Specifies the starting and ending quantities adsorbed
and number of points to insert.
Load Table. Imports values from another file.
Save Table. Saves the current table as a .QNT file.
Apply. Applies all table changes.
Generates the Heat of Adsorption data in a graphical format.
Generates a graph showing quantities of gas adsorbed versus the
temperature.
Removes the selected sample from the list.
Use to show a graphic on the report header.
Height/Width. Enter the height and width of the selected graphic.
These values determine the graphic's appearance on the generated
report.
Select then enter a report title to appear on the report header.
Generates a tabular report of the included samples that contains the
numeric values contributed by each sample.
