A Advanced Reports - Python Module
S
CRIPTS
Run a Script
1. Open a sample file with a Complete file status.
2. Select Advanced in the view selector drop-down list at the bottom of the window.
3. Select the Report Options tab.
4. Highlight Advanced in the Selected Reports list box, then click Edit.
5. On the Advanced Report Options window, click Add.
6. Select one or more python scripts then click Select. The selected scripts become a part of
the drop-down list in the Available Scripts section of the Advanced Report Options window.
7. In the Select Reports section, select up to five Advanced reports in the drop-down lists.
8. Click OK.
9. Click Preview on the Report Options tab to view all reports selected in the previous window.
Remove a Script
Select the script in the Available Scripts box then click Remove. The script is removed from the
application however, the original .py text file is not affected.
Edit a Script
Selections
Add [button]
Edit [button]
Overlay samples
[check box]
Pressures [button]
A - 4
Description
Adds one or more scripts to the Available Scripts box. The added
scripts then become available as options in the Selected Reports
section.
Edits the script stored within the application but does not affect the
original .py text file.
Select to enable the overlay sample files process.
Select to include or exclude pressures from the report.
Calculation pressure range. Enter the minimum and maximum
n
pressures to be used in the pressure table.
Cancel. Discards any changes or cancels the current process.
n
Exclude All. Select to exclude all pressure points in the table.
n
Include All. Select to include all pressure points in the table.
n
OK. Saves and closes the active window.
n
