Environmental Factors
Environmental Factors
Power
The TriStar II Plus is designed to operate with a universal input power supply (100 / 115 / 230 VAC) at
50 or 60 Hz. Noise-free power of the correct voltage and frequency, with a safety earth ground, should
be available through a standard wall receptacle. The power outlet should be able to supply 15 amps @
100 or 115 VAC + 10% or 7.5 amps @ 230 VAC +10%. These requirements can be checked by using
a Circuit Analyzer (available at most hardware or electronic supply houses) or a multimeter. There
should also be sufficient outlets for the computer, dry roughing pump, monitor, and printer and any
other peripheral devices.
DO:
• Install the instrument and peripheral devices on their own, dedicated power line.
DO NOT:
• Place other devices on the same power line; for example, motors, generators, or ovens.
Temperature and Humidity
Temperature and humidity must be controlled to within the following:
Temperature: 15 to 35 °C operating; 0 to 50 °C non-operating
Humidity:
20 to 80% relative, non-condensing
DO NOT:
• Allow room temperature or humidity to exceed limits.
• Install the instrument where it is exposed to direct sunlight.
• Locate the instrument near air conditioning or heating vents.
Hazards & Precautions
Inform Micromeritics of any on-site conditions that may present hazards to Micromeritics employees
or equipment. Advise Micromeritics of any precautions that need to be taken.
Safety Measures
Inform Micromeritics of any safety equipment, requirements, or procedures necessary for Micromerit-
ics employees to enter and install the TriStar II Plus system at your facility.
4
TriStar II Plus Preinstallation Instructions and Checklist
303-42870-01 (Rev B) - Mar 2015
