VLT® AutomationDrive FC 302
Operating Guide
FC 302
Line reactor overtemperature trip [°C (°F)]
dU/dt filter overtemperature trip [°C (°F)]
Sine-wave filter overtemperature trip [°C (°F)]
Typical power loss is at normal conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions.) These
1
values are based on a typical motor efficiency (IE/IE3 border line). Lower efficiency motors add to the power loss in the drive. Applies to dimension-
ing of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control card power
consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/knowledge-center/energy-efficiency-direc-
tive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B each
add only 4 W.
2 Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Efficiency measured at nominal current. For energy efficien-
cy class, see the Ambient Conditions section. For part load losses, see drives.danfoss.com/knowledge-center/energy-efficiency-directive/#/.
See also Input Power Option Losses section.
3
If using an output filter, the output frequency is limited further. See
4
10.1.2 Electrical Data, 525–690 V AC
Table 105: Electrical Data, Mains Supply 3x525–690 V AC
FC 302
High/normal overload
High overload=150% or 160% torque for a
duration of 60 s. Normal overload=110% tor-
que for a duration of 60 s.
Typical shaft output at 550 V [kW]
Typical shaft output at 575 V [hp]
Typical shaft output at 690 V [kW]
Enclosure size
Output current (3-phase)
Continuous (at 550 V) [A]
Intermittent (60 s overload) (at 550 V) [A]
Continuous (at 575/690 V) [A]
Intermittent (60 s overload) (at 575/690 V) [A]
Continuous kVA (at 550 V) [kVA]
Continuous kVA (at 575 V) [kVA]
Continuous kVA (at 690 V) [kVA]
Maximum input current
Continuous (at 525 V) [A]
Continuous (at 575/690 V) [A]
Maximum number and size of cables per phase
2
- Mains [mm (AWG)]
166 | Danfoss A/S © 2021.10
10.3.1 Motor Output (U, V,
N90K N110
HO NO HO
75 90 90
100 125 125
90 110 110
D9h D9h
113 137 137
170 151 206
108 131 131
162 144 197
103 125 125
108 131 131
129 157 157
109 132 132
104 126 126
2x95 (2x3/0 mcm) 2x95 (2x3/0 mcm)
N450
150 (302)
150 (302)
150 (302)
W).
N132
NO HO NO
110 110 132
150 150 200
132 132 160
D9h
162 162 201
178 243 221
155 155 192
171 233 211
147 147 183
154 154 191
185 185 230
156 156 193
149 149 185
2x95 (2x3/0 mcm)
AQ262139143212en-000301 / 130R0879
Specifications
N500
150 (302)
150 (302)
150 (302)
N160
HO NO
132 160
200 250
160 200
D10h
201 253
301 278
192 242
288 266
183 230
191 241
229 289
193 244
185 233
2x185 (2x350 mcm)
