Table 145: Power Losses for Contactor Option, 525–690 V
Model
–
N90K
N110
N132
N160
N200
N250
N315
N355
N400
N500
N560
N630
N710

11.6.2 Fusible Disconnect Losses

Table 146: Power Losses for Fusible Disconnect Option, 380–500 V
Model
–
N90K
N110
N132
N160
N200
N250
N315
N355
N400
N450
N500
198 | Danfoss A/S © 2021.10
525–550 V [W]
NO HO
7 5
10 7
15 10
23 15
33 23
47 33
63 47
40 28
50 33
64 50
72 64
83 62
76 56
380–440 V [W]
NO HO
71 49
89 59
131 90
142 91
155 105
233 155
188 156
202 158
233 176
282 233
305 241
551–690 V [W]
NO HO
6 4
9 6
13 9
21 13
30 21
43 30
58 43
37 26
45 30
59 45
72 59
76 57
69 51
441–500 V [W]
NO HO
57 40
76 48
121 76
119 83
132 88
193 132
151 127
168 127
194 168
222 194
246 189
