VLT® AutomationDrive FC 302
Operating Guide
1
2
-XD11.1
3
-XD4.1
4
Illustration 34: Split Shipment Electrical Connections (D10h Sine-wave Cabinet)
1
Additional terminal connections
2
Thermal protection wiring harness to drive cabinet
3
DC-link harness to fan supply in drive cabinet
68 | Danfoss A/S © 2021.10
-XDL.1
U
V
W
4
5
5
Cabinet heater supply harness to drive cabinet
Motor cables (U/V/W) to motor terminals (U/V/W) in
drive cabinet
AQ262139143212en-000301 / 130R0879
Electrical Installation
