10.9.5 E6h Enclosed Drive Exterior Dimensions

55
(2.2)
1
2000
(78.7)
100
6
(3.9)
600 (23.6) /
800 (31.5)
(23.6)
Illustration 83: Dimensions for E6h Enclosure with Standard Pedestal
1 Passive harmonic filter/line reactor cabinet
2 Options cabinet
3 E6h drive cabinet
188 | Danfoss A/S © 2021.10
2
600 (23.6)
600
3
800 (23.6)
400
(15.8)
4 Sine-wave cabinet
5 dU/dt cabinet
6 Standard pedestal
AQ262139143212en-000301 / 130R0879
