VLT® AutomationDrive FC 302
Operating Guide

4.7 Cooling Requirements

OVERHEATING
Improper mounting can result in overheating and reduced performance.
-
Install the drive following the installation and cooling requirements.
Ensure that top and bottom clearance for air cooling is provided. Clearance requirement: 225 mm (9 in).
Provide sufficient airflow flow rate. See
Consider derating for temperatures starting between 45 °C (113 °F) and 50 °C (122 °F) and elevation 1000 m (3300 ft) above sea
level.
The enclosed drive, excluding the input power options cabinet, utilizes a back-channel cooling concept that removes the air used to
cool the heat sink. The heat sink cooling air carries approximately 90% of the heat out of the back channel of the drive. Different
back-channel cooling kits are available to redirect the airflow based on individual needs.

4.8 Airflow Rates

Table 39: Airflow Rates for D9h Enclosure
Cabinet
Back-channel fan [m
PHF/line reactor
450 (265)
Drive
420 (250)
dU/dt
Sine-wave
900 (530)
Top entry/top exit
Table 40: Airflow Rates for D10h Enclosure
Cabinet
Back-channel fan [m
PHF/line reactor
515 (303)
Input options
Drive
840 (500)
dU/dt
Sine-wave
900 (530)
Top entry/top exit
Table 41: Airflow Rates for E5h Enclosure
Cabinet
Back-channel fan [m
PHF/line reactor
765 (450)
Input options
Drive
994 (585)
42 | Danfoss A/S © 2021.10
N O T I C E
4.8 Airflow
Rates.
3
/hr (cfm)]
Drive module top fan [m
102 (60)
3
/hr (cfm)]
Drive module top fan [m
204 (120)
3
/hr (cfm)]
Drive module top fan [m
595 (350)
Mechanical Installation
3
/hr (cfm)]
Cabinet door fan [m
150 (90)
3
/hr (cfm)]
Cabinet door fan [m
510 (310)
315 (185)
3
/hr (cfm)]
Cabinet door fan [m
510 (310)
335 (200)
AQ262139143212en-000301 / 130R0879
3
/hr (cfm)]
3
/hr (cfm)]
3
/hr (cfm)]
