Table 149: Power Losses for Non-fusible Disconnect Option, 525–690
Model
–
N90K
N110
N132
N160
N200
N250
N315
N355
N400
N500
N560
N630
N710

11.6.4 Molded-case Circuit Breaker (MCCB) Losses

Table 150: Power Losses for MCCB Option, 380–500 V
Model
–
N90K
N110
N132
N160
N200
N250
N315
N355
N400
N450
N500
200 | Danfoss A/S © 2021.10
525–550 V [W]
NO HO
4 2
5 4
8 5
12 8
17 12
24 17
33 24
42 29
52 35
20 16
23 20
32 24
44 32
380–440 V [W]
NO HO
25 18
38 25
56 38
54 35
80 54
120 80
62 52
80 62
92 70
112 92
92 73
551–690 V [W]
NO HO
3 2
5 3
7 5
11 7
16 11
22 16
30 22
38 27
47 32
19 14
23 19
30 22
40 30
441–500 V [W]
NO HO
20 14
32 20
51 32
45 32
68 45
100 68
50 42
66 50
77 66
88 77
74 57
