VLT® AutomationDrive FC 302
Operating Guide
Table 119: Mains Contactor Switches for VLT
N90K
IEC 185 A/1000 V
Eaton P/N XTCE400M22A
UL 185 A/1000 V
Eaton P/N XTCE400M22A
Table 120: Mains Contactor Switches for VLT
N315
IEC 400 A/1000 V
Eaton P/N XTCE400M22A
UL 400 A/1000 V
Eaton P/N XTCE400M22A
Table 121: Mains Contactor Switches for VLT
IEC
Eaton P/N
UL
Eaton P/N

10.8.3 Fusible Disconnect Switches

The fusible disconnector switch is an option that safely isolates the drive from the mains with a fuse switch mounted below the
drive module. All units ordered and supplied with a factory-installed fusible disconnect switch have a fuse built in to the switch. The
fuse has been sized to meet 65kA SCCR for the system. The input voltage and power rating of the drive determines the specific class
or gG fuse. The input voltage and power rating are found on the product nameplate.
Table 122: Fusible Disconnect Switches for VLT
N90K
IEC 400 A/690 V
ABB P/N OS400D30P
UL 400 A/600 V
ABB P/N OS400J30
Table 123: Fusible Disconnect Switches for VLT
N315
IEC 1250 A/690 V
ABB P/N OS1250D30P
UL 800 A/600 V
ABB P/N OS800L30
182 | Danfoss A/S © 2021.10
AutomationDrive FC 302 Enclosed Drive Models N90K–N250, 525–690 V
®
N110 N132
185 A/1000 V 185 A/1000 V
XTCE400M22A XTCE400M22A
185 A/1000 V 185 A/1000 V
XTCE400M22A XTCE400M22A
AutomationDrive FC 302 Enclosed Drive Models N315–N560, 525–690 V
®
N355
580 A/1000 V
XTCE580N22A
580 A/1000 V
XTCE580N22A
AutomationDrive FC 302 Enclosed Drive Models N630–N710, 525–690 V
®
N630
580 A/1000 V
XTCE580N22A
820 A/1000 V
XTCE820N22A
AutomationDrive FC 302 Enclosed Drive Models N90K–N250, 380–500 V
®
N110 N132
400 A/690 V 400 A/690 V
OS400D30P OS400D30P
400 A/600 V 400 A/600 V
OS400J30 OS400J30
AutomationDrive FC 302 Enclosed Drive Models N315–N500, 380–500 V
®
N355
1250 A/690 V
OS1250D30P
1200 A/600 V
OS1200L30
N160
400 A/1000 V
XTCE400M22A
400 A/1000 V
XTCE400M22A
N400 N500
580 A/1000 V 580 A/1000 V
XTCE580N22A XTCE580N22A
580 A/1000 V 580 A/1000 V
XTCE580N22A XTCE580N22A
N710
820 A/1000 V
XTCE820N22A
1000 A/1000 V
XTCEC10N22A
N160
630 A/690 V
OS630D30P
600 A/600 V
OS600J30
N400 N450
1250 A/690 V 1250 A/690 V
OS1250D30P OS1250D30P
1200 A/600 V 1200 A/600 V
OS1200L30 OS1200L30
Specifications
N200 N250
400 A/1000 V 400 A/1000 V
XTCE400M22A XTCE400M22A
400 A/1000 V 400 A/1000 V
XTCE400M22A XTCE400M22A
N560
580 A/1000 V
XTCE580N22A
580 A/1000 V
XTCE580N22A
N200 N250
630 A/690 V 630 A/690 V
OS630D30P OS630D30P
600 A/600 V 800 A/600 V
OS600J30 OS800L30
N500
1250 A/690 V
OS1250D30P
1200 A/600 V
OS1200L30
AQ262139143212en-000301 / 130R0879
