VLT® AutomationDrive FC 302
Operating Guide
Table 9: Power Rating Codes
Character position
10–12
Table 10: Drive Module PCB Coating Codes
Character position
13
Table 11: Plinth (Pedestal) Codes
Character position
14
Table 12: Drive Module Braking and Safety Codes
Character position
15
Danfoss A/S © 2021.10
Code
Description
90K
(N90K) 90 kW/125 hp
110
(N110) 110 kW/150 hp
132
(N132) 132 kW/200 hp
160
(N160) 160 kW/250 hp
200
(N200) 200 kW/300 hp
250
(N250) 250 kW/350 hp
315
(N315) 315 kW/450 hp
355
(N355) 355 kW/500 hp
400
(N400) 400 kW/550 hp
450
(N450) 450 kW/600 hp
500
(N500) 500 kW/650 hp
560
(N560) 560 kW/750 hp
630
(N639) 630 kW/900 hp
710
(N710) 710 kW/1000 hp
800
(N800) 800 kW/1200 hp
Code
Description
C
Coated PCB
R
Coated PCB + ruggedized
Code
Description
1
100 mm high pedestal
2
200 mm high pedestal
4
400 mm high pedestal
5
Marine pedestal
Code
Description
X
No brake IGBT
B
Brake IGBT
T
Safe Torque Off
U
Brake IGBT + Safe Torque Off
Product Overview
AQ262139143212en-000301 / 130R0879 | 25
