7.
Tighten the terminals in accordance with the specifications shown in
Example
1
2
Illustration 56: Connection Points for Mains to Input Power Option (Enclosed Drive Configured Without Power Options Cabinet)
1
Lower cover
2
Input power terminals (contactor option is shown)
Danfoss A/S © 2021.10
10.11 Fastener Torque
3
DC terminals
4
Grounding bar
AQ262139143212en-000301 / 130R0879 | 101
Electrical Installation
Ratings.
3
4
