Table 147: Power Losses for Fusible Disconnect Option, 525–690 V
Model
–
N90K
N110
N132
N160
N200
N250
N315
N355
N400
N500
N560
N630
N710

11.6.3 Non-fusible Disconnect Losses

Table 148: Power Losses for Non-fusible Disconnect Option, 380–500 V
Model
–
N90K
N110
N132
N160
N200
N250
N315
N355
N400
N450
N500
Danfoss A/S © 2021.10
525–550 V [W]
NO HO
29 20
41 29
63 41
71 45
101 70
118 84
151 112
191 135
134 90
154 119
173 154
208 155
282 208
380–440 V [W]
NO HO
8 6
13 8
19 13
29 19
44 29
65 44
25 21
32 25
36 27
43 36
55 43
551–690 V [W]
NO HO
27 18
37 27
57 37
65 41
92 64
108 77
138 102
175 125
123 83
141 109
173 141
190 142
258 190
441–500 V [W]
NO HO
7 5
11 7
17 11
25 17
37 25
54 37
20 17
26 20
30 26
34 30
44 34
