VLT® AutomationDrive FC 302
Operating Guide
Table 27: C Option Software Codes
Character position
34
Table 28: D Option Codes
Character position
35
Table 29: EMC Filter Codes
Character position
36
Table 30: Reserved Code
Character position
37–39
Table 31: Documentation Language Codes
Character position
40

3.5 Power Ratings, Weight, and Dimensions

Table 32: Power Ratings and Dimensions for D9h–D10h and E5h–E6h Enclosures (Standard Configurations)
Enclosed drive
Rated power at 380–500 V [kW (hp)]
(1)
Rated power at 525–690 V [kW (hp)]
(2)
Protection rating
Drive cabinet
Height [mm (in)]
(3)
Width [mm (in)]
(4)
Danfoss A/S © 2021.10
Code Description
X No software option
0 VLT® Synchronizing Controller MCO 350 (FC 302 only)
1 VLT® Positioning Controller MCO 351 (FC 302 only)
Code Description
X No D option
0 VLT® 24 V DC Supply MCB 107
1 VLT® Real time clock option MCB 117
Code
2
4
Code
X
G
F
D9h D10h
90–132 (125–200) 160–250 (250–350)
90–132 (100–150) 160–315 (200–350)
IP21 (NEMA 1)/ IP21 (NEMA 1)/IP54
IP54 (NEMA 12) (NEMA 12)
D9h D10h
2100 (82.7) 2100 (82.7)
400 (15.8) 600 (23.6)
Description
(H2) RFI class A2 (C3)
(H4) RFI class A1 (C2)
Code Description
X None
Description
nd
English, no 2 language
English + German
English + French
E5h
315–400 (450–550)
355–560 (400–600)
IP21 (NEMA 1)/IP54
(NEMA 12)
E5h
2100 (82.7)
600 (23.6)
AQ262139143212en-000301 / 130R0879 | 31
Product Overview
E6h
450–500 (600–650)
630–710 (650–750)
IP21 (NEMA 1)/IP54
(NEMA 12)
E6h
2100 (82.7)
800 (31.5)
