10.8.2 Contactor Switches

The mains contactor is an option. All units ordered and supplied with a factory-installed contactor require a Class L/J branch circuit
fusing to meet the 65 kA SCCR for the drive system.
This option makes it possible to connect or disconnect the drive from the mains by using a control switch on the control compart-
ment door or an external switch. The external switch must be wired to terminals XD0. See
Enclosed Drives and 5.4 Wiring Overview for E5h and E6h Enclosed
switches (1 normally open and 1 normally closed). These switches are on the sides of the contactor. By default, the NO auxiliary
switch is wired at the factory and used by the system.
Rated operation current @ 230 V
Rated operation current @ 380 V
Rated operation current @ 500 V
Conventional thermal current, Ith
Rated voltage
Rated impulse withstand voltage
Table 117: Mains Contactor Switches for VLT
N90K
IEC 185 A/1000 V
Eaton P/N XTCE400M22A
UL 185 A/1000 V
Eaton P/N XTCE400M22A
Table 118: Mains Contactor Switches for VLT
N315
IEC 580 A/1000 V
Eaton P/N XTCE580N22A
UL 820 A/1000 V
Eaton P/N XTCE820N22A
Danfoss A/S © 2021.10
AutomationDrive FC 302 Enclosed Drive Models N630–N710, 525–690 V
N630
1000 A/690 V
OFAA4AM1000
1000 A/600 V
A4BY1000
AutomationDrive FC 302 Enclosed Drive Models N90K–N250, 380–500 V
®
N110 N132
185 A/1000 V 185 A/1000 V
XTCE400M22A XTCE400M22A
185 A/1000 V 185 A/1000 V
XTCE400M22A XTCE400M22A
AutomationDrive FC 302 Enclosed Drive Models N315–N500, 380–500 V
®
N355
580 A/1000 V
XTCE580N22A
820 A/1000 V
XTCE820N22A
N710
1000 A/690 V
OFAA4AM1000
1100 A/600 V
A4BY1100
5.3 Wiring Overview for D9h and D10h
Drives. The mains contactor is supplied with 2 sets of auxiliary
N160
400 A/1000 V
XTCE400M22A
400 A/1000 V
XTCE400M22A
N400 N450
580 A/1000 V 820 A/1000 V
XTCE580N22A XTCE820N22A
820 A/1000 V 1000 A/1000 V
XTCE820N22A XTCEC10N22A
AQ262139143212en-000301 / 130R0879 | 181
Specifications
N200 N250
580 A/1000 V 500 A/1000 V
XTCE400M22A XTCE500M22A
400 A/1000 V 580 A/1000 V
XTCE580N22A XTCE580N22A
N500
820 A/1000 V
XTCE820N22A
1000 A/1000 V
XTCEC10N22A
6 A
4 A
1.5 A
10 A
500 V AC
600 V AC
