VLT® AutomationDrive FC 302
Operating Guide
-RFI Radio frequency interference (RFI) filter
R1 Resistor
-RF5 Passive harmonic filter (PHF) L0
-RF4 PHF inductors
-CA5 PHF capacitors
-QA2 PHF contactor
-RFL Line reactor
-QAF PHF relay
-QB7 Molded-case circuit breaker (MCCB)
-QA3 Mains contactor
-QB2 Mains fused disconnect
Danfoss A/S © 2021.10
-QB8 Mains disconnect
-MA7 dU/dt and sine-wave filter fans
-MA8 PHF fans
-RF2 Sine-wave filter inductor
-CA4 Sine-wave filter capacitor
-RF1 dU/dt filter inductor
-CA3 dU/dt filter capacitor
-RF3 Common-mode filter
-MA1 Motor (customer side)
-TA1 Drive module
LCP Local control panel
