VLT® AutomationDrive FC 302
Operating Guide
Danfoss provides the following mains options for the enclosed drive:
•

Panel fuses

• Fusible disconnect
• Non-fusible disconnect
• Contactor
• Molded-case circuit breaker (MCCB)
10.8.1 Panel Fuses
Panel fuses are an option for upstream protection, and are included only if the fusible disconnect option is selected. The panel fuses
can be ordered as either a UL class fuse for UL variant or a gG fuse for IEC variant.
Table 112: Panel Fuses for VLT
®
N90K
IEC (Type gG) 250 A/500 V
Mersen P/N NH1GG50V250
UL (Class J/L/T) 300 A/600 V
Mersen P/N A4J300
Table 113: Panel Fuses for VLT
®
N315
IEC (Type gG) 800 A/500 V
Mersen P/N NH4GG50V800
UL (Class J/L/T) 800 A/600 V
Mersen P/N A4BY800
Table 114: Panel Fuses for VLT
®
N90K
IEC (Type gG) 250 A/690 V
Mersen P/N NH2GG69V250
UL (Class J/L/T) 175 A/600 V
Mersen P/N A4J175
Table 115: Panel Fuses for VLT
®
N315
IEC (Type gG) 500 A/690 V
Mersen P/N NH3GG69V500
UL (Class J/L/T) 600 A/600 V
Mersen P/N A4J600
180 | Danfoss A/S © 2021.10
AutomationDrive FC 302 Enclosed Drive Models N90K–N250, 380–500 V
N110 N132
315 A/500 V 355 A/500 V
NH2GG50V315 NH2GG50V355
350 A/600 V 400 A/600 V
A4J350 A4J400
AutomationDrive FC 302 Enclosed Drive Models N315–N500, 380–500 V
N355
1000 A/500 V
NH4GG50V1000
1000 A/600 V
A4BY1000
AutomationDrive FC 302 Enclosed Drive Models N90K–N250, 525–690 V
N110
250 A/690 V
NH2GG69V250
200 A/600 V
A4J200
AutomationDrive FC 302 Enclosed Drive Models N315–N560, 525–690 V
N355
500 A/500 V
NH3GG69V500
600 A/600 V
A4J600
N160
425 A/500 V
NH3GG50V425
500 A/600 V
A4J500
N400
1000 A/500 V
NH4GG50V1000
1000 A/600 V
A4BY1000
N132 N160
250 A/690 V 315 A/690 V
NH2GG69V250 NH2GG69V315
250 A/600 V 350 A/600 V
A4J250 A4J350
N400
630 A/500 V
NH4GG69V630
650 A/600 V
A4BY650
Specifications
N200 N250
630 A/500 V 630 A/500 V
NH3AGG50V630 NH3AGG50V630
600 A/600 V 750 A/600 V
A4J600 AABY750
N450 N500
1000 A/500 V 1250 A/500 V
NH4GG50V1000 NH4GG50V1250
1100 A/600 V 1200 A/600 V
A4BY1100 A4BY1200
N200 N250
355 A/690 V 425 A/690 V
NH3GG69V355 NH3GG69V425
400 A/600 V 500 A/600 V
A4J400 A4J500
N500 N560
800 A/500 V 800 A/500 V
NH4GG69V800 NH4GG69V800
750 A/600 V 800 A/600 V
A4BY750 A4BY800
AQ262139143212en-000301 / 130R0879
