Table 129: Non-fusible Disconnect Switches for VLT
N90K
IEC 400 A/690 V
ABB P/N OT400E30
UL 400 A/600 V
ABB P/N OT400U30
Table 130: Non-fusible Disconnect Switches for VLT
N315
IEC 630 A/690 V
ABB P/N OT630E30
UL 600 A/600 V
ABB P/N OT600U30
Table 131: Non-fusible Disconnect Switches for VLT
IEC
ABB P/N
UL
ABB P/N

10.8.5 Molded-case Circuit Breakers

The molded-case circuit breaker (MCCB) is an option that combines a temperature-sensitive device with a current-sensitive electro-
magnetic device to protect the drive.
Table 132: MCCB Part Numbers for VLT
N90K
IEC 400 A/690 V
ABB P/N T5L400
UL 400 A/600 V
ABB P/N T5L400BW
Table 133: MCCB Part Numbers for VLT
N315
1000 A/690 V
IEC
ABB T71000LSPR231 DS-
P/N LS
1200 A/600 V
UL
ABB T7L1200PR231/P
P/N
184 | Danfoss A/S © 2021.10
AutomationDrive FC 302 Enclosed Drive Models N90K–N250, 525–690 V
®
N110 N132
400 A/690 V 400 A/690 V
OT400E30 OT400E30
400 A/600 V 400 A/600 V
OT400U30 OT400U30
AutomationDrive FC 302 Enclosed Drive Models N315–N560, 525–690 V
®
N355 N400
630 A/690 V 630 A/690 V
OT630E30 OT630E30
600 A/600 V 600 A/600 V
OT600U30 OT600U30
AutomationDrive FC 302 Enclosed Drive Models N630–N710, 525–690 V
®
N630
1250 A/690 V
OT1250E30
1200 A/600 V
OT1200U30
AutomationDrive FC 302 Enclosed Drive Models N90K–N250, 380–500 V
®
N110 N132
400 A/690 V 400 A/690 V
T5L400 T5L400
400 A/600 V 400 A/600 V
T5L400BW T5LQ400BW
AutomationDrive FC 302 Enclosed Drive Models N315–N500, 380–500 V
®
N355 N400
1250 A/690 V 1250 A/690 V
T71250LSPR231 DS- T71250LSPR231 DS-LS
LS
1200 A/600 V 1200 A/600 V
T7L1200PR231/P T7LQ1200PR231/P
N160 N200
630 A/690 V 630 A/690 V
OT630E30 OT630E30
600 A/600 V 600 A/600 V
OT600U30 OT600U30
N500
1000 A/690 V
OT1000E30
800 A/600 V
OT800U30
N710
1250 A/690 V
OT1250E30
1200 A/600 V
OT1200U30
N160 N200
800 A/690 V 800 A/690 V
T6L800 T6L800
600 A/600 V 600 A/600 V
T6L600BW T6LQ600BW
N450
1250 A/690 V
T71250LSPR231 DS-
LS
1600 A/600 V
T8V1600PR232/P
AQ262139143212en-000301 / 130R0879
Specifications
N250
630 A/690 V
OT630E30
600 A/600 V
OT600U30
N560
1000 A/690 V
OT1000E30
800 A/600 V
OT800U30
N250
800 A/690 V
T6L800
800 A/600 V
T6LQ800BW
N500
1600 A/690 V
T71600LSPR231 DS-
LS
1600 A/600 V
T8V1600PR232/P
