3.4.3 Type Code Identification

Table 4: Product Group Code
Character position
1–3
Table 5: Drive Series Codes
Character position
4–6
Table 6: Low-harmonic Filter Codes
Character position
7
Table 7: Mains Voltage Codes
Character position
8
Table 8: Norms and Standards Codes
Character position
9
24 | Danfoss A/S © 2021.10
Enclosure size (380–500 V)
–
–
–
Code
PLV
Code Description
102 VLT
103 VLT
202 VLT
302 VLT
Code Description
T None
P Passive filter, THDi=5%, 50 Hz
H Passive filter, THDi=8%, 50 Hz
L Passive filter, THDi=5%, 60 Hz
U Passive filter, THDi=8%, 60 Hz
Code Description
4 380–480 V
5 380–500 V
7 525–690 V (525–600 V for UL)
Code
I
U
Enclosure size (525–690 V)
E5h
E6h
E6h
Description
®
VLT Enclosed Drives
®
HVAC Drive FC 102
®
Refrigeration Drive FC 103
®
AQUA Drive FC 202
®
AutomationDrive FC 302
Description
IEC
UL
Product Overview
AQ262139143212en-000301 / 130R0879
