VLT® AutomationDrive FC 302
Operating Guide
Table 111: Line Reactor Configuration for D9h–D10h and E5h–E6h Enclosures, 525–690 V
Enclosure
D9h
D9h
D9h
D10h
D10h
D10h
D10h
E5h
E5h
E5h
E5h
E6h
E6h

10.7.3 dU/dt Filter Specifications

Voltage rating
Motor frequency derating, 50 Hz
Motor frequency derating, 60 Hz
Motor frequency derating, 100 Hz
Minimum switching frequency
Maximum switching frequency
Overload capacity

10.7.4 Sine-wave Filter Specifications

Voltage rating
Nominal current @ 50 Hz
Motor frequency with derating
Motor frequency without derating
Minimum switching frequency
Maximum switching frequency
Overvoltage category
Overload capacity
Ambient temperature [°C (°F)]
Storage temperature [°C (°F)]
Transport temperature [°C (°F)]
Altitude during operation
178 | Danfoss A/S © 2021.10
Model
N90K
N110
N132
N160
N200
N250
N315
N355
N400
N500
N560
N630
N710
(1)
(2)
Impedance [%)
212 A and 315 A for 380–500 V, 137 A and 222 A for 525–690 V
2 kHz for 380–500 V, 1.5 kHz for 525–690 V
100% current (no derating) up to 1000 m (3280 ft)
1% current derating for each 100 m (328 ft) above 1000 m (3280
AQ262139143212en-000301 / 130R0879
Specifications
2.30
2.78
3.29
2.92
3.67
3.08
3.67
2.89
3.11
3.55
4.04
3.19
3.70
3x380–690 V
Nominal
Nominal
0.75 x nominal
No limit
Nominal switching frequency
150% for 60 s, every 10 minutes
3x380–500 V and 525–690 V AC
Up to 150 Hz
0–60 Hz
Nominal switching frequency
OVC III as defined in IEC61800-5-1
150% for 60 s every 10 minutes
-15 (5) to +60 (140)
-40 (-40) to +70 (158)
-40 (-40) to +70 (158)
(1)
ft)
