VLT® AutomationDrive FC 302
Operating Guide
FC 302
Control card overtemperature trip [°C (°F)]
PHF overtemperature trip [°C (°F)]
Line reactor overtemperature trip [°C (°F)]
dU/dt filter overtemperature trip [°C (°F)]
Sine-wave filter overtemperature trip [°C (°F)]
Typical power loss is at normal conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions.) These
1
values are based on a typical motor efficiency (IE/IE3 border line). Lower efficiency motors add to the power loss in the drive. Applies to dimension-
ing of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control card power
consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/knowledge-center/energy-efficiency-direc-
tive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B each
add only 4 W.
Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Efficiency measured at nominal current. For energy efficien-
2
cy class, see the Ambient Conditions section. For part load losses, see drives.danfoss.com/knowledge-center/energy-efficiency-directive/#/.
See also Input Power Option Losses section.
3
If using an output filter, the output frequency is limited further. See
4
Table 102: Electrical Data, Mains Supply 3x380–500 V AC
FC 302
High/normal overload
High overload=150% or 160% torque for a duration of 60 s.
Normal overload=110% torque for a duration of 60 s.
Typical shaft output at 400 V [kW]
Typical shaft output at 460 V [hp]
Typical shaft output at 500 V [kW]
Enclosure size
Output current (3-phase)
Continuous (at 400 V) [A]
Intermittent (60 s overload) (at 400 V) [A]
Continuous (at 460/500 V) [A]
Intermittent (60 s overload) (at 460/500 V) [A]
Continuous kVA (at 400 V) [kVA]
Continuous kVA (at 460 V) [kVA]
Continuous kVA (at 500 V) [kVA]
Maximum input current
Continuous (at 400 V) [A]
Continuous (at 460/500 V) [A]
Maximum number and size of cables per phase
2
- Mains [mm (AWG)]
162 | Danfoss A/S © 2021.10
N90K
75 (167)
145 (293)
150 (302)
150 (302)
150 (302)
10.3.1 Motor Output (U, V, W).
N160
HO NO
160 200
250 300
200 250
D10h
315 395
473 435
302 361
453 397
218 274
241 288
262 313
304 381
291 348
2x185 (2x350 mcm) 2x185 (2x350 mcm)
Specifications
N110 N132
75 (167) 75 (167)
145 (293) 145 (293)
150 (302) 150 (302)
150 (302) 150 (302)
150 (302) 150 (302)
N200 N250
HO NO HO
200 250 250
300 350 350
250 315 315
D10h D10h
395 480 480
593 528 720
361 443 443
542 487 665
274 333 333
288 353 353
313 384 384
381 463 463
348 427 427
2x185 (2x350 mcm)
AQ262139143212en-000301 / 130R0879
NO
315
450
355
588
647
535
589
407
426
463
567
516
