Danfoss D9h Operating Manual page 26

VLT® AutomationDrive FC 302
Operating Guide
Table 13: Mains Option Codes
Character position
16–17
Table 14: Output Filter Codes
Character position
18
Table 15: Reserved Code
Character position
19
26 | Danfoss A/S © 2021.10
Code Description
MX None
M1 Fusible disconnect
M2 Non-fusible disconnect
M3 Circuit breaker (MCCB)
M4 Mains contactor
M5 AC reactor
M6 Fuses
MA Fusible disconnect + mains contactor
MB Non-fusible disconnect + mains contactor
MC AC reactor + fusible disconnect
MD AC reactor + fusible disconnect + mains contactor
ME AC reactor + non-fusible disconnect
MF AC reactor + circuit breaker (MCCB)
MG AC reactor + mains contactor
MH AC reactor + non-fusible disconnect + mains contactor
Code Description
X None
D dU/dt filter
S Sine-wave filter
C Common-mode filter
1 Common-mode + dU/dt filters
2 Common-mode + sine-wave filters
Code Description
X None
Product Overview
AQ262139143212en-000301 / 130R0879
