VLT® AutomationDrive FC 302
Operating Guide
Table 21: Protection Rating Codes
Character position
26–27
Table 22: Door-mounted Codes
Character posi- Code
tion
28–29 XX
D1
D2
D3
D4
D5
DA
DB
DC
DE
Table 23: A Option Codes
Character position
30
Danfoss A/S © 2021.10
Description
None
Signal lights and reset button
Emergency switch off + emergency push-button
STO with emergency push-button (basic functional safety)
STO/SS1 with emergency push-button + safely limited speed (TTL encoder)
STO/SS1 with emergency push-button + safely limited speed (HTL encoder)
Indicator lights and reset button + emergency switch off and emergency push-button
Indicator lights and reset button + STO with emergency push-button (basic functional safety)
Indicator lights and reset button + STO/SS1 with emergency push-button + safely limited speed
(TTL encoder)
Indicator lights and reset button + STO/SS1 with emergency push-button + safely limited speed
(HTL encoder)
Code Description
X No A option
0 VLT® PROFIBUS DP-V1 MCA 101
4 VLT® DeviceNet MCA 104 (FC 102/FC 202/FC 302 only)
6 VLT® CANopen MCA 105 (FC 302 only)
8 VLT® EtherCAT MCA 124 (FC 302 only)
G VLT® LonWorks MCA 108 (FC 102 only)
J VLT® BACnet MCA 109 (FC 102 only)
K VLT® BACnet/IP MCA 125 (FC 102 only)
L VLT® PROFINET MCA 120
N VLT® EtherNet/IP MCA 121 (FC 102/FC 202/FC 302 only)
Q VLT® Modbus TCP MCA 122 (FC 102/FC 202/FC 302 only)
T VLT® PROFIBUS Converter VLT 3000 MCA 113 (FC 302 only)
U VLT® PROFIBUS Converter VLT 5000 MCA 114 (FC 302 only)
Code Description
21 IP21
54 IP54
AQ262139143212en-000301 / 130R0879 | 29
Product Overview
