VLT® AutomationDrive FC 302
Operating Guide
-RFI Radio frequency interference (RFI) filter
R1 Resistor
-RF5 Passive harmonic filter (PHF) L0
-RF4 PHF inductors
-CA5 PHF capacitors
-QA2 PHF contactor
-RFL Line reactor
-QAF PHF relay
-QB7 Molded-case circuit breaker (MCCB)
-QA3 Mains contactor
-QB2 Mains fused disconnect

11.6 Input Power Option Losses

The loss values shown in this section are typical of the worst case operating conditions. For normal conditions, typical power loss is
expected to be within ±15%. The tolerance relates to differences in voltage and cable conditions. These values are based on a typi-
cal motor efficiency (IE/IE3 border line). Lower efficiency motors increase power loss in the drive and filters, which affect the dimen-
sioning of the drive and filter cooling. If the switching frequency is higher than the default setting, the power losses can increase.
For output filters, an increase in motor frequency will increase the losses. In this situation, follow the derating guidelines specified in
the product-specific Design Guide.

11.6.1 Contactor Losses

Table 144: Power Losses for Contactor Option, 380–500 V
Model
–
N90K
N110
N132
N160
N200
N250
N315
N355
N400
N450
N500
Danfoss A/S © 2021.10
380–440 V [W]
NO HO
16 11
25 16
36 25
57 36
42 28
63 42
62 51
79 62
91 69
74 61
94 74
-QB8 Mains disconnect
-MA7 dU/dt and sine-wave filter fans
-MA8 PHF fans
-RF2 Sine-wave filter inductor
-CA4 Sine-wave filter capacitor
-RF1 dU/dt filter inductor
-CA3 dU/dt filter capacitor
-RF3 Common-mode filter
-MA1 Motor (customer side)
-TA1 Drive module
LCP Local control panel
NO
13
21
33
47
36
52
50
66
76
58
76
AQ262139143212en-000301 / 130R0879 | 197
Appendix
441–500 V [W]
HO
9
13
21
33
24
36
42
50
66
51
58
