Commissioning
5.6

Video Signal

Measurement chart menu
Go to the
The diagram in the large graphic window on the right shows the video signal of the receiver line in different post-process-
ing states.
The video signal in the graphics window shows the spectral distribution over the pixels of the receiver line. Left 0 %
(small distance) and right 100 % (large distance). The corresponding measured value is marked by a vertical line (peak
marking).
The diagram starts automatically when the website is accessed.
3
2
1
Video signal
Fig. 34 website
Video Signal
The website contains the following functions:
The LED visualizes the state of measurement value transmission.
1
- green: measured value transmission in progress
- yellow: waiting for data in trigger state
- gray: measured value transmission paused
The data query is controlled with the
stops the diagram; you can still continue to use the data selection and zoom functions.
Save
ing. opens the Windows selection dialog for the file name and the save location to save the selected video
signals to a CSV file. This contains all pixels, their (selected) intensity in % and other parameters.
Click on the button
2 In the left-hand window, the video curves to be displayed can be switched on or off during or after the measure-
ment. Inactive curves are grayed out and can be added by clicking on the check mark. The changes become
effective when you save the settings.
You can show or hide the individual signals using the eye symbols
ground.
- 0xRAW: Raw signal (uncorrected CCD signal)
- 0xDARK: Dark corrected signal (raw signal minus dark level table)
- 0xLIGHT: Light corrected signal (dark corrected signal corrected with the light source table)
- 0xDARK_TABLE: Dark value table (generated in response to dark referencing)
- 0xLIGHT_TABLE: Light value table (generated in response to light referencing)
3 To scale the intensity axis in the graph for the measured values (Y axis), you can use
Manual
(= manual scaling).
4 All changes only become effective when you click on the
confocalDT IFD2410/2411/2415
. Show video signal display with
Play/Pause/Stop/Save
(Start), display the measurement results.
Video
.
buttons of the measured values transmitted.
. The calculation continues in the back-
Save settings
button.
4
5
6
7
8
9
10
11
Pause
pauses the record-
Auto
(= automatic scaling) or
Page 43
