8.3.2.38 Object 3A10h: Statistics
3A10
RECORD Statistic 1
Subindices
0
VAR
Number of entries
1
VAR
Enable
2
VAR
Signal
4
VAR
Infinite
5
VAR
Depth
6
VAR
Reset
50
VAR
Available signals part 0
51
VAR
Available signals part 1
52
VAR
Available signals part 2
53
VAR
Available signals part 3
54
VAR
Available signals part 4
55
VAR
Available signals part 5
Objects 3A10h to 3A12h generate three statistics signals.
Sub-index 50 ... 55 Corresponds to the command META_STATISTICSIGNAL.
Sub-index 6 corresponds to the STATISTIC command.
3 signals are generated for each statistics object activated. They are listed in object 0x3E00. The statistics function can
also be applied to user signals.
Example: You want distance 1 (channel 1) to output the minimum and the maximum measured values using all previous
distance values.
Activating a statistics object
3A10:01(Enable) to TRUE. Distance 1 (01DIST1) is selected as signal by default. If you would like to display statistics for
a different signal, you will need to select the required signal in sub-index 2.
- Settings for all previous distance values
3A10:04 (Infinite) to True (STATISTICSIGNAL – INFINITE)
Assigning a user-defined signal to the PDO
The newly generated signal names appear in object 0x3E00h:
The minimum distance is output in 0x7C00h and the maximum distance is output in 0x7C02h.
Select PDO
UserCalcOutput01 – 0x7C00h is selected with object 1B00h, and 0x7C02h is output with object 1B10h
1B00
UserCalc01 TxPDOMap
UserCalcOutput01
1B08
UserCalc02 TxPDOMap
UserCalcOutput02
1B10
UserCalc03 TxPDOMap
UserCalcOutput03
Therefore, the following selections need to be made in 0x1C13h, 0x1B00h and 0x1B10h before PreOp is switched to
SafeOp:
0x00 (0)1B00
clear sm pdos (0x1C13)
0x1B00 (6912)
download pdo 0x1C13:01 index
0x1B10 (6928)
download pdo 0x1C13:02 index
0x02 (2)
download pdo 0x1C13 count
confocalDT IFD2410/2411/2415
55
0x7C00
0x7C01
Extract from TxPDO Mapping,
Chap. 8.3.1.7
see
0x7C02
Unsigned8
ro
BOOL
rw
Visible string rw
BOOL
rw
Unsigned16
rw
BOOL
wo
Visible string
Visible string
Visible string
Visible string
Visible string
Visible string
