Commissioning
5.3

Positioning the Target

Position the target as centrally as possible within the measuring range.
100 %
50
0
SMR
SMR
Sensor
Range LED
5.4

Select Sensor

The function is valid for the IFD2411 measuring system.
Controller and sensor(s) are coordinated to one another at the factory.
Settings > Sensor
Go to the
Select the required sensor from the list.
The calibration data of up to 20 different sensors can be saved in the controller. Calibration is only possible at Micro-Ep-
silon.
confocalDT IFD2410/2411/2415
Displacement
MMR EMR
Target
Measuring range (MR)
menu.
LED Range
Red
intensity
range
Yellow
Green
Range
The LED on the front of the measuring system indi-
cates the position of the target relative to the sensor.
No target present or target
outside of
measuring range
Target close to mid of measur-
ing range
Target within the measuring
range
Page 41
