Data Recording

6.2.1

Measuring Rate

IFD2410/2411: The measuring rate can be set continuously in a range from 0.1 kHz to 8 kHz. The increment is 1 Hz.
IFD2415: The measuring rate can be set continuously in a range from 0.1 kHz to 25 kHz. The increment is 1 Hz.
The selection of the measuring rate is made in the menu
Select the desired measuring rate.
Observing the video signal is useful for selecting the measuring rate.
Procedure:
Position the target in the middle of the measuring range,
get a high signal intensity that is not oversaturated.
Sensor
Fig. 41 Defining measuring range and output signal
To do this, observe the
LED Status
Red
Intensity Yellow
Green
Intensity
- If the LED changes to red, increase the measuring rate.
Intensity
- If the LED changes to yellow, increase the measuring rate.
Choose a measuring rate that makes the
If necessary, change the exposure mode, use the
Use the required measuring rate, and adjust the exposure time. Or let the exposure time define possible measuring
rates.
Intensity
If the signal is low (
surements, but measuring accuracy might not correspond to the specified technical data.
confocalDT IFD2410/2411/2415
100 %
50
0
SMR Midrange
Measuring
SMR
Target
Intensity
LED.
Description
Signal saturated
Signal too low
Signal OK
Intensity
LED is yellow) or saturated (
Settings Data recording
>
see Fig. 41. Keep adjusting the measuring rate until you
Displacement
EMR
range (MR)
LED light up green.
manual mode,
see Chap. 6.2.5
Intensity
LED is red), the controller will carry out mea-
Measuring rate
> .
