Term Definitions, Glossary

SMR Start of measuring range. A start of measuring range (SMR) must be kept between each sensor and the target.
Minimal distance between the front sensor face and the target.
MMR Mid of measuring range
EMR End of measuring range (start of measuring range + measuring range)
Maximum distance between the front sensor face and the target.
MB Measuring range
Sensor
Fig. 1 Measuring range and output measuring system
Minimum target thickness
Maximum target thickness
confocalDT IFD2410/2411/2415
100 %
50
0
SMR MMR
Measuring
SMR
Target
see Chapter Technical Data
Sensor measuring range x refractive index of target
Displacement
EMR
range (MR)
