Safety
1.3

Notes on Product Marking

1.3.1

Notes on CE Marking

Please note the following for the confocalDT IFD2410/2411/2415 measuring system:
- EU Directive 2014/30/EU
- EU Directive 2011/65/EU
Products which carry the CE mark satisfy the requirements of the EU directives cited and the relevant applicable har-
monized European standards (EN). The measuring system is designed for use in industrial and home applications and
meets the requirements.
The EU Declaration of Conformity is available to the responsible authorities according to EU Directive, Article 10.
1.3.2

Notes on UKCA Marking

Please note the following for the confocalDT IFD2410/2411/2415 measuring system:
- SI 2016 No. 1091:2016-11-16 The Electromagnetic Compatibility Regulations 2016
- SI 2012 No. 3032:2012-12-07 The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic
Equipment Regulations 2012
Products which bear the CE mark meet the requirements of the EU directives cited and the relevant applicable harmo-
nized European standards. The measuring system is designed for use in industrial environments.
The UKCA marking and the technical documentation are available to the responsible authorities according to UKCA
directives.
1.4

Intended Use

- The measuring system confocalDT IFD2410/2411/2415 is designed for use in an industrial environment. It is used for
ƒ Displacement, distance, movement and thickness measurement,
ƒ measuring the position of parts or machine components
- The measuring system must only be operated within the limits specified in the technical data see
The measuring system must only be used in such a way that no persons are endangered or machines are dam-
aged in the event of malfunction or total failure of the sensor.
Take additional precautions for safety and damage prevention in case of safety-related applications.
1.5

Proper Environment

Protection class
Operating temperature range
Storage temperature range
Humidity
Ambient pressure:
Shock (DIN EN 60068-2-27)
Vibration (DIN EN 60068-2-6)
EMC
confocalDT IFD2410/2411/2415
confocalDT IFD2410/2415
IP64, front side
+5 ... +50 °C
15 g/6 ms on XY axis, 1000 shocks each
2 g / 20 ... 500 Hz on XY axis, 10 cycles each
As per EN 61000-6-3 / EN 61326-1 (Class B) Emitted interference; EN 61000-6-2
/ EN 61326-1 Immunity to interference
confocalDT IFD2411
Sensor
IP64, front side
+5 ... +70 °C
-20 ... +70 °C
5 ... 95% (non-condensing)
Atmospheric pressure
Chap. 2.4.
Controller
IP40
+5 ... +50 °C
