Appendix | ASCII Communication with Controller
A 5 ASCII Communication with Controller
A 5.1 General
The ASCII commands can be sent to the controller via the RS422 interface or Ethernet (Port 23). All commands, inputs
and error reports are in English. A command always consists of the command name and zero or several parameters that
are separated with a space and end in LF. If spaces are used in parameters, the parameter must be placed in quotation
marks, e.g. "Password with space".
Example: Switching on output via RS422
OUTPUT RS422
Note: Must contain LF, but can also be CR LF.
Explanation: LF Line feed (hex 0A)
CR Carriage return (hex 0D)
Enter (depending on system, hex 0A or hex 0D0A)
The currently set parameter value is reset if a command is invoked without parameters.
The output format is:
<Command name> <Parameter1> [<Parameter2> [...]]
The response can be used again without changes as a command for setting the password. Optional parameters are only
returned as well if this is necessary.
After a command is processed, a line break and a prompt ("->") is always returned. In the event of an error, an error
message beginning withExx, where xx stands for a unique error number, comes before the prompt. Moreover, instead
of error messages, warning messages ("Wxx") may be output. Warnings are structured like error messages, such as "If
Xenon lamp is too hot...". Warnings do not prevent commands from being executed.
A 5.2 Commands Overview
Group Chapter
General
Chap. A 5.3.1.1
Chap. A 5.3.2.2
Chap. A 5.3.1.3
Chap. A 5.3.1.4
Chap. A 5.3.1.5
Chap. A 5.3.1.6
Chap. A 5.3.1.7
Chap. A 5.3.1.8
User level
Chap. A 5.3.2.1
Chap. A 5.3.2.2
Chap. A 5.3.2.3
Chap. A 5.3.2.4
Chap. A 5.3.2.5
Inputs
Chap. A 5.3.3
confocalDT 2410/2411/2415
Command
HELP
GETINFO
ECHO
PRINT
SYNC
TERMINATION
RESET
RESETCNT
LOGIN
LOGOUT
GETUSERLEVEL
STDUSER
PASSWD
MFILEVEL
Brief information
Help
Controller information
Reply type
Parameter overview
Synchronization
Termination resistor
Boot sensor
Reset counter
Change user level
Change to user level User
User level query
Set standard user
Change password
Input level multifunction inputs
