Appendix | ASCII Communication with Controller
All values greater than 262072 are error values and are defined as follows:
Error code Description
262073 Scaling error RS422 interface underflow
262074 Scaling error RS422 interface overflow
262075
Data volume too large for baud rate selected
262076 No peak is present.
262077 Peak is before the measuring range (MB)
262078 Peak is behind the measuring range (MB)
262079 Measured value cannot be calculated
For all other data outputs except the measured value data, the limitations are defined in the relevant sections.
1) This error occurs when more data is to be output than can be transmitted at the selected baud rate at the selected measuring fre-
quency. There are the following options of rectifying this error:
- Increase baud rate, see
- Decrease measuring frequency, see
- Reduce data volume; if 2 data words were selected, reduce to one data word, see
- Reduce output data rate, see
confocalDT 2410/2411/2415
Chap. A 5.3.7
Chap. A 5.3.9.5
Chap. A 5.3.12.2
1
Chap. A 5.3.13
