Appendix | ASCII Communication with Controller
A 5.3.4

Sensor

A 5.3.4.1 Information on Calibration Tables
SENSORTABLE
->SENSOR TABLE
Position Sensor name,
0, IFS2404-3,
1, IFS2404-6,
2, IFS2404-2,
->
Output of all available (taught-in) sensors.
SENSORTABLE
The command is valid for the IFD2411.
Command is mapped in the SDO 0x3152.
A 5.3.4.2 Sensor Information
SENSORINFO
Output of information about the sensor (name, measuring range and serial number).
->SENSORINFO
Position:
Name:
Measurement range:
Serial:
->
A 5.3.4.3

Dark Correction

DARKCORR
Performing the dark referencing for the current sensor. The dark referencing depends on the sensor and is saved sepa-
rately for each individual sensor in the controller.
Command is mapped in the SDO 0x3011.
DARKCORR_PRINT
Lists the values of the dark correction table.
A 5.3.4.4

LED

LED OFF | ON
Switches the LED of the respective channel on or off.
A 5.3.4.5 Control Input Measurement Light Source
LEDSOURCE [SOFTWAREONLY | MFI1 | MFI2]
- SOFTWAREONLY: The measurement light source can only be controlled by software; via ASCII command LED ON/
OFF or web interface
- MFI1: Control of the measurement light source via selected multifunction input MFI1
- MFI2: Control of the measurement light source via selected multifunction input MFI2
Command is mapped in the SDO 0x3133.
confocalDT 2410/2411/2415
Measurement range,
3.000mm,
6.000mm,
2.000mm,
0
BG
3,000 mm
12345678
Serial number
05110005
05120003
00001335
Page 151
