Mounting | confocalDT 2411
4.3.12

Synchronization (Inputs/Outputs)

4.3.12.1 General

SYNC+ Sync-
- The and
more controllers
multifunction input 1
- The pin
external synchronization source, such as a function generator
- The termination resistor R

4.3.12.2 Internal Synchronization

One IFC2411 controller (master) synchronizes one or more controllers (slaves).
Synchronization
Fig. 26 Connections and signal level internal synchronization
Activate the termination resistor (120 Ohm) in the last controller (slave n) in the chain.
Star synchronization
Sync+
Connect pins
(master) in a star shape to pins
from controller 2 (slave) to controller n, in order to
synchronize two or more controller to one another,
see Fig. 27
- Sub-loop length less than 30 m in star synchronization
Use shielded cables with twisted wires.
Connect the cable shield to pin 3 of the 5-pin terminal block.
Program controller 1 to
Master
Slave 1
Length max.
30 meter
Fig. 27 Synchronization of multiple controllers, star-shaped on the left, daisy-chained on the right
Connect all GND connections of the supply to one another if the controllers are not fed by a common power sup-
ply.
i
If the sensors are operated by way of the EtherCAT interface, then synchronization can also be achieved without the
synchronization line.
confocalDT 2410/2411/2415
pins on the 5-pin clamping sleeve: Symmetrical output/input for synchronization of two or
on the 5-pin clamping sleeve: Input for synchronization of a controller with an
(120 Ohm) can be switched on or off via software.
T
IFC2411
5-pin clamping sleeve
1
2
3
5
Sync-
and from controller 1
Sync+ Sync-
and
Master
and all other controller to
Slave n
Signal Level
Sync + RS422
Sync - RS422
Cable shield
GND
Chain synchronization
Connect pins
(master) to pins
2 (slave 1).
Connect the pins of the following controller to
synchronize two or more controller to one another,
see Fig. 27
- Total line length less than 30 m in chain synchroniza-
tion
Slave
.
Sync+ Sync-
and from controller 1
Sync+ Sync-
and
Master
Sum of partial cables
 30 meter
Slave 1
from controller
Slave n
Page 34
